TAP650 Series
Manufacturer: Ohmite
Beta
⌘K
PLANAR RESISTORS - CHASSIS MOUNT 650W HEATSINKABLE 4.7 OHM
| Part | Mounting Feature | Coating, Housing Type | Composition | Tolerance | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Temperature Coefficient | Lead Style | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Power (Watts) | Resistance | Height - Seated (Max) | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Ohmite | Flanges | Epoxy Coated | Thick Film | 5 % | 32.5 mm | 1.28 in | -55 C | 150 °C | 150 ppm/°C | M5 Threaded | 2.559 in | 60 mm | 65 mm | 2.362 in | 600 W | 4.7 Ohms | ||
 Ohmite | Flanges Screw Holes | Epoxy Coated | Thick Film | 5 % | 0.532 " | -55 C | 150 °C | 150 ppm/°C | Wire Leads | 2.264 in | 51.5 mm | 57.5 mm | 2.028 in | 650 W | 1000 Ohms | 13.5 mm | Rectangular Case |
