OSTTA03 Series
Manufacturer: On Shore Technology Inc.
Beta
⌘K
TERM BLK 3POS SIDE ENT 7.5MM PCB
| Part | Torque - Screw | Torque - Screw | Screw Thread | Housing Material | Clamp Material - Plating [custom] | Screw Material - Plating | Operating Temperature [Min] | Operating Temperature [Max] | Current | Mating Orientation | Pitch | Pitch | Wire Termination | Features | Number of Levels | Color | Positions Per Level | Wire Gauge [Min] | Wire Gauge [Max] | Mounting Type | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 On Shore Technology Inc. | 3.5 Lb-In | 0.4 Nm | M3 | Thermoplastic | Stainless Steel | Steel - Zinc Plated | -30 ░C | 105 ░C | 16 A | Horizontal with Board | 0.295 in | 7.5 mm | Screw - Leaf Spring Wire Guard | Interlocking (Side) | 1 | Blue | 3 | 14 AWG | 22 AWG | Through Hole | |
 On Shore Technology Inc. | 2.6 Lb-In | 0.3 Nm | M3 | Thermoplastic | Stainless Steel | Steel - Zinc Plated | -30 ░C | 105 ░C | 16 A | Horizontal with Board | 0.197 in | 5 mm | Screw - Leaf Spring Wire Guard | Interlocking (Side) | 1 | Blue | 3 | 14 AWG | 26 AWG | Through Hole | |
 On Shore Technology Inc. | 3.5 Lb-In | 0.4 Nm | M3 | Thermoplastic | Stainless Steel | Steel - Zinc Plated | -30 ░C | 105 ░C | 15 A | Horizontal with Board | 0.2 in | 5.08 mm | Screw - Leaf Spring Wire Guard | Interlocking (Side) | 1 | Blue | 3 | 14 AWG | 22 AWG | Through Hole | 300 VDC |
 On Shore Technology Inc. | 3.5 Lb-In | 0.4 Nm | M3 | Polyamide (PA) Nylon | Stainless Steel | Steel Galvanized - Chromate Plated | -33 °C | 120 °C | 16 A | Horizontal with Board | 0.394 in | 10 mm | Screw - Leaf Spring Wire Guard | Interlocking (Side) | 1 | 3 | 14 AWG | 22 AWG | Through Hole |
