BS-23 Series

Catalog

12-10 AWG VINYL INSULATED BUTTED SEAM FLANGED BLOCK FORK TERMI

Part	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Material - Insulation	Length - Termination [x]	Length - Termination [x]	Length - Ring Center to Termination [x]	Length - Ring Center to Termination [x]	Insulation	Mounting Type	Stud/Tab Size	Width - Outer Edges [x]	Width - Outer Edges [x]	Contact Finish	Features	Contact Material	Wire Gauge [Min]	Wire Gauge [Max]	Color	Length - Overall [x]	Length - Overall [x]	Terminal Type	Termination
3M Electronic Specialty BS-23-6-P	6.35 mm	0.25 in	Vinyl	0.55 in	13.97 mm	7.37 mm	0.29 in	Insulated	Free Hanging (In-Line)	6 Stud	0.32 in	8.13 mm	Tin	Butted Seam	Copper ETP	10 AWG	12 AWG	Yellow	26.16 mm	1.03 in	Flanged	Crimp
3M Electronic Specialty BS-23-10	3.43 mm	0.135 "		0.25 in	6.35 mm	7.37 mm	0.29 in	Non-Insulated	Free Hanging (In-Line)	10 Stud	0.32 in	8.13 mm	Tin	Butted Seam	Copper ETP	10 AWG	12 AWG		18.54 mm	0.73 in	Flanged	Crimp
3M Electronic Specialty BS-23-6-NB	6.35 mm	0.25 in	Nylon Polyamide (PA)	0.55 in	13.97 mm	7.37 mm	0.29 in	Insulated	Free Hanging (In-Line)	6 Stud	0.32 in	8.13 mm	Tin		Copper ETP	10 AWG	12 AWG	Yellow	26.16 mm	1.03 in	Flanged	Crimp
3M Electronic Specialty BS-23-10-W				0.25 in	6.35 mm	7.37 mm	0.29 in	Non-Insulated	Free Hanging (In-Line)	10 Stud	0.32 in	8.13 mm	Tin	Brazed Seam	Copper ETP	10 AWG	12 AWG		18.54 mm	0.73 in	Flanged	Crimp
