ASETDV Series

Catalog

STANDARD CLOCK OSCILLATORS 10.0 MHZ CMOS SMD

Part	Current - Supply (Disable) (Max) [Max]	Function	Frequency Stability	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Type	Current - Supply (Max) [Max]	Frequency	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Base Resonator [custom]	Package / Case	Output	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply
Abracon LLC ASETDV-10.000MHZ-XY-T	10 µA	Enable/Disable	10 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	1.2 mm	0.047 "	XO (Standard)	4.8 mA	10 MHz	3.2	2.5	4-SMD	Crystal	4-SMD No Lead	CMOS	Surface Mount	-40 C	105 ░C	1.8 V 2.5 V 3.3 V
Abracon LLC ASETDV-12.000MHZ-XY-T	10 µA	Enable/Disable	10 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	1.2 mm	0.047 "	XO (Standard)	4.8 mA	12 MHz	3.2	2.5	4-SMD	Crystal	4-SMD No Lead	CMOS	Surface Mount	-40 C	105 ░C	1.8 V 2.5 V 3.3 V
Abracon LLC ASETDV-60.000MHZ-LY-T	10 µA	Enable/Disable	10 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	1.2 mm	0.047 "	XO (Standard)	8 mA	60 MHz	3.2	2.5	4-SMD	Crystal	4-SMD No Lead	CMOS	Surface Mount	-40 C	85 °C	1.8 V 2.5 V 3.3 V
