FS225R12 Series

Manufacturer: INFINEON

Catalog

THE FS225R12OE4 IS A SIXPACK IGBT4 - E4 MODULE IN A ECONOPACK™ + D HOUSING FOR INDUSTRIAL APPLICATIONS UP TO 1200 V AND 225 A.

Part	Current - Collector Cutoff (Max) [Max]	IGBT Type	Vce(on) (Max) @ Vge, Ic	Configuration	Mounting Type	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Power - Max [Max]	Input	Input Capacitance (Cies) @ Vce	Package / Case	Voltage - Collector Emitter Breakdown (Max) [Max]	Current - Collector (Ic) (Max) [Max]
INFINEON FS225R12OE4BOSA1	3 mA	Trench Field Stop	2.15 V	Full Bridge Inverter	Chassis Mount	Module	125 °C	-40 C	1250 W	Standard	13 nF	Module	1200 V	350 A
INFINEON FS225R12KE3BOSA1	5 mA	Trench Field Stop	2.15 V	Full Bridge	Chassis Mount	Module	125 °C	-40 C	1150 W	Standard	16 nF	Module	1200 V	325 A
INFINEON FS225R12OE4PBOSA1	3 mA	Trench Field Stop	2.15 V	Full Bridge	Chassis Mount	Module	150 °C	-40 C	20 mW	Standard	13 nF	Module	1200 V	450 A
