WP-PA Series
Manufacturer: Phoenix Contact
Beta
⌘K
SPIRAL WRAPS, SLEEVES, TUBING & CONDUIT 50 METER HOSE PRICED/SLD PER METER
| Part | Environment Protection [custom] | Features | Liquid Protection | Color | Operating Temperature [Max] | Operating Temperature [Min] | Material | Material Flammability Rating | Diameter - Outside [diameter] | Diameter - Outside [diameter] | Type | Type Attributes | Diameter - Inside [diameter] | Diameter - Inside [diameter] | Length | Length | Diameter - Outside, Non-Expanded [diameter] | Diameter - Outside, Non-Expanded [diameter] | Diameter - Inside, Non-Expanded [diameter] | Diameter - Inside, Non-Expanded [diameter] | Heat Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | UV Resistant | Acid Resistant Airtight Self Extinguishing Solvent Resistant | Fluid Resistant Gasoline Resistant Oil Resistant | Black | 115 °C | -40 C | Halogen Free Nylon Polyamide (PA) | UL94 V-0 | 10 mm | 0.394 in | Wire Loom Protective Hose | Convoluted Corrugated | 0.256 " | 6.5 mm | |||||||
 Phoenix Contact | UV Resistant | Acid Resistant Airtight Self Extinguishing Solvent Resistant | Fluid Resistant Gasoline Resistant Oil Resistant | Black | 115 °C | -40 C | Halogen Free Nylon Polyamide (PA) | UL94 V-0 | 15.8 mm | 0.622 in | Wire Loom Protective Hose | Convoluted Corrugated | 0.472 in | 12 mm | |||||||
 Phoenix Contact | UV Resistant | Acid Resistant Airtight Solvent Resistant | Fluid Resistant Gasoline Resistant Oil Resistant | Black | 105 ░C | -40 C | Halogen Free Nylon Polyamide (PA) | UL94 HB | 21.2 mm | 0.835 in | Wire Loom Protective Hose | Convoluted Corrugated | 0.65 " | 16.51 mm | 1 m | 3.28 ft | |||||
 Phoenix Contact | UV Resistant | Acid Resistant Solvent Resistant Vibration Resistant | Gasoline Resistant Oil Resistant | Black | 105 ░C | -40 C | Halogen Free Nylon Polyamide (PA) | UL94 V-0 | Slit Wrap | Slit Harness | 34.5 mm | 1.358 in | 1.142 in | 29 mm | Flame Retardant |
