TR141 Series
Manufacturer: ITT Cannon, LLC
Beta
⌘K
CIRCULAR CONNECTOR, TRIDENT RINGLOCK SERIES, PLUG, 12, SOCKET, CABLE MOUNT, 14-12 ROHS COMPLIANT: YES
| Part | Note | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Housing Color | Number of Positions | Connector Type | Mounting Type | Contact Type | Shell Size - Insert [Min] | Shell Size - Insert [Max] | Orientation | Features | Type | Shielding | Fastening Type | Material Flammability Rating | Ingress Protection | Mounting Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ITT Cannon, LLC | Contacts Not Included | Circular | -55 C | 105 ░C | Black | 12 | Plug Housing | Free Hanging (In-Line) | Crimp and Solder Cup | 14 | 12 | Keyed | Coupling Nut | For Female Sockets | Unshielded | Detent Lock | UL94 V-0 | ||
 ITT Cannon, LLC | Contacts Not Included | Circular | -55 C | 105 ░C | Black | 12 | Receptacle Housing | Panel Mount | Crimp Solder Solder Cup | 14 | 12 | Keyed | For Female Sockets | Unshielded | Detent Lock | UL94 V-0 | IP65 - Dust Tight Water Resistant | Flange | |
 ITT Cannon, LLC | Contacts Not Included | Circular | -55 C | 105 ░C | Black | 12 | Plug Housing | Free Hanging (In-Line) | Crimp and Solder Cup | 14 | 12 | Keyed | Coupling Nut | For Male Pins | Unshielded | Detent Lock | UL94 V-0 |
