FDSD144 Series
Manufacturer: Belden Inc.
Beta
⌘K
CBL FIBER OPTIC 125UM SINGLEMODE
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Jacket (Insulation) Material | Features | Features | Jacket Color | Type | Tensile Strength | Ratings | Core Diameter [diameter] | Cladding Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 70 °C | -40 C | Poly-Vinyl Chloride (PVC) | Armored | 144 Fibers | Black | Singlemode | 81.6 kg | OFCP | 9 µm | 125 µm | 37.08 mm | 1.46 in | Multiple Fibers |
 Belden Inc. | 70 °C | -40 C | Poly-Vinyl Chloride (PVC) | 144 Fibers Rip Cord | Black | Singlemode | 81.6 kg | OFNP | 9 µm | 125 µm | 27.05 mm | 1.065 in | Multiple Fibers | |
 Belden Inc. | 70 °C | -40 C | Low Smoke Zero Halogen (LSZH) | 144 Fibers Rip Cord | Black | Singlemode | 81.6 kg | OFNR | 9 µm | 125 µm | 27.94 mm | 1.1 " | Multiple Fibers | |
Belden Inc. | ||||||||||||||
Belden Inc. | 70 °C | -40 C | Poly-Vinyl Chloride (PVC) | Armored | 144 Fibers | Black | Singlemode | 81.6 kg | OFCR | 9 µm | 125 µm | 38.35 mm | 1.51 in | Multiple Fibers |
