T523 Series
Manufacturer: KEMET
Beta
⌘K
TANTALUM CAPACITORS - POLYMER 35V 56UF 20% 7343-15 -55 / +105 ESR=70MOHMS AEC-Q200
| Part | Manufacturer Size Code | Operating Temperature [Min] | Operating Temperature [Max] | ESR (Equivalent Series Resistance) | Voltage - Rated | Lifetime @ Temp. | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Type | Capacitance | Tolerance | Height - Seated (Max) [Max] | Height - Seated (Max) | Mounting Type | Package / Case | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | W | -55 C | 105 ░C | 70 mOhm | 35 V | 2000 Hrs | 0.169 " | 7.3 mm | 0.287 " | 4.3 mm | Molded | 56 µF | 20 % | 0.059 " | 1.5 mm | Surface Mount | 2917 (7343 Metric) | General Purpose |
