3SU1153 Series

Manufacturer: Siemens

Catalog

ILLUMINATED PUSHBUTTON, MOM, BLU

Part	Electrical Life	Mechanical Life	Current Rating (Amps)	Termination Style	Actuator Type	Illumination Type, Color	Panel Cutout Dimensions [diameter]	Switch Function	Illumination Voltage (Nominal)	Voltage Rating - DC	Color - Actuator/Cap	Circuit	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Type	Mounting Type	Voltage Rating - AC
Siemens 3SU11530AB503BA0	10000000 Cycles	3000000 Cycles	10 A	Spring Terminal	Button Round	Blue LED	22.3 mm	Off-Mom	110 VAC	500 V	Blue	SPST-NO	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB701FA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	LED White	22.3 mm	Off-Mom On-Mom	110 VAC	500 V	Clear	DPST-NO/NC	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB201FA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	LED Red	22.3 mm	Off-Mom On-Mom	110 VAC	500 V	Red	DPST-NO/NC	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB701BA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	LED White	22.3 mm	Off-Mom	110 VAC	500 V	Clear	SPST-NO	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB601FA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	LED White	22.3 mm	Off-Mom On-Mom	110 VAC	500 V	White	DPST-NO/NC	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB201CA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	LED Red	22.3 mm	On-Mom	110 VAC	500 V	Red	SPST-NC	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB601BA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	LED White	22.3 mm	Off-Mom	110 VAC	500 V	White	SPST-NO	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB303BA0	10000000 Cycles	3000000 Cycles	10 A	Spring Terminal	Button Round	LED Yellow	22.3 mm	Off-Mom	110 VAC	500 V	Yellow	SPST-NO	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB703BA0	10000000 Cycles	3000000 Cycles	10 A	Spring Terminal	Button Round	LED White	22.3 mm	Off-Mom	110 VAC	500 V	Clear	SPST-NO	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
Siemens 3SU11530AB001FA0	10000000 Cycles	3000000 Cycles	10 A	Screw Terminal	Button Round	Amber LED	22.3 mm	Off-Mom On-Mom	110 VAC	500 V	Amber	DPST-NO/NC	IP66 IP67 IP69K	-25 °C	70 °C	Illuminated Standard	Panel Mount Front	500 V
