3RQ301 Series
Manufacturer: Siemens
Beta
⌘K
RELAY GEN PURPOSE SPDT 3A 230V
| Part | Switching Voltage [Max] | Coil Type | Operating Temperature [Min] | Operating Temperature [Max] | Features | Relay Type | Contact Material | Coil Voltage | Coil Voltage | Operate Time | Termination Style | Load - Max Switching | Contact Form | Mounting Type | Approval Agency | Contact Rating (Current) | Release Time | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Siemens | 250 VAC | Non Latching | -25 °C | 60 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 230 VDC | 230 VAC | 9 ms | Screw Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 19 ms | |
Siemens | 250 VAC | Non Latching | -25 °C | 60 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 12 ms | Screw Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 14 ms | 24 VAC | ||
 Siemens | 250 VAC | Non Latching | -25 °C | 60 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 115 VDC | 8 ms | Spring Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 17 ms | 115 VAC | |
Siemens | 250 VAC | Non Latching | -25 °C | 60 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 230 VDC | 230 VAC | 9 ms | Spring Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 19 ms | |
Siemens | 250 VAC | Non Latching | -25 °C | 60 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 12 ms | Spring Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 14 ms | 24 VAC | ||
Siemens | 250 VAC | Non Latching | -40 C | 70 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 6 ms | Spring Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 11 ms | 110 VDC | ||
Siemens | 250 VAC | Non Latching | -40 C | 70 °C | Lighted Indicator | General Purpose | Silver Tin Oxide (AgSnO) | 5 ms | Spring Terminal | 750 VA | SPDT (1 Form C) | DIN Rail | CCC CSA EAC UL | 3 A | 10 ms | 24 VDC |
