PXT Series
Manufacturer: Chemi-Con
Beta
⌘K
ALUMINUM ORGANIC POLYMER CAPACITORS 100UF 16V
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | ESR (Equivalent Series Resistance) | Applications | Mounting Type | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Voltage - Rated | Size / Dimension [diameter] | Size / Dimension [diameter] | Ripple Current @ High Frequency | Surface Mount Land Size [y] | Surface Mount Land Size [x] | Tolerance | Ripple Current @ Low Frequency | Capacitance | Lifetime @ Temp. | Type | Surface Mount Land Size [y] | Surface Mount Land Size [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Chemi-Con | -55 C | 105 ░C | Radial Can - SMD | 45 mOhm | General Purpose | Surface Mount | 6.1 mm | 0.24 " | 16 V | 0.197 in | 5 mm | 2 A | 0.209 in 5.3 mm | 0.209 in 5.3 mm | 20 % | 100 mA | 100 µF | 15000 Hrs | Polymer | ||
 Chemi-Con | -55 C | 105 ░C | Radial Can - SMD | 26 mOhm | General Purpose | Surface Mount | 6.1 mm | 0.24 " | 6.3 VDC | 0.248 " | 6.3 mm | 2.6 A | 6.6 mm | 6.6 mm | 20 % | 130 mA | 330 µF | 15000 Hrs | Polymer | 0.26 in | 0.26 in |
