857-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish | Termination | Pitch | Pitch | Mounting Type | Features | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows [custom] | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row [custom] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Gender | Color | Read Out | Contact Material | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Gold | Solder | 3.96 mm | 0.156 in | Board Edge Straddle Mount | Card Extender | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | Black | Dual | Copper Alloy | Non Specified - Dual Edge |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Gold | Solder | 3.96 mm | 0.156 in | Right Angle Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Flush Mount M3 Threaded Insert Top Opening | Female | Black | Single | Copper Alloy | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Tin | Solder | 3.96 mm | 0.156 in | Board Edge Straddle Mount | Card Extender | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Female | Black | Dual | Copper Alloy | Non Specified - Dual Edge | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Tin | Solder | 3.96 mm | 0.156 in | Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | Black | Dual | Copper Alloy | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Gold | Solder | 3.96 mm | 0.156 in | Right Angle Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | Black | Single | Copper Alloy | Non Specified - Dual Edge | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Tin | Solder | 3.96 mm | 0.156 in | Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 4-40 Flush Mount Threaded Insert Top Opening | Female | Black | Dual | Copper Alloy | Non Specified - Dual Edge | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Gold | Solder Eyelet(s) | 3.96 mm | 0.156 in | Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | Black | Dual | Copper Alloy | Non Specified - Dual Edge | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Tin | Solder | 3.96 mm | 0.156 in | Right Angle Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Female | Black | Single | Copper Alloy | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Gold | Solder | 3.96 mm | 0.156 in | Right Angle Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Female | Black | Single | Copper Alloy | Non Specified - Dual Edge | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Tin | Solder Eyelet(s) | 3.96 mm | 0.156 in | Through Hole | Semi Bellows | 125 °C | -40 C | 2 | 62 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Female | Black | Dual | Copper Alloy | Non Specified - Dual Edge |
