123-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
BOARD TO BOARD & MEZZANINE CONNECTORS
| Part | Current Rating (Amps) | Termination Post Length | Termination Post Length | Material Flammability Rating | Contact Resistance | Termination | Contact Finish - Mating | Number of Positions or Pins (Grid) | Pitch - Mating | Pitch - Mating | Contact Material - Post [custom] | Contact Finish - Post | Type [custom] | Type [custom] | Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Features | Contact Material - Mating | Pitch - Post | Pitch - Post | Contact Finish Thickness - Mating | Housing Material | Number of Positions or Pins (Grid) [y] | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [x] | Type | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 40 | 0.1 " | 2.54 mm | Brass | Tin | 15.24 mm | 0.6 in | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | |||||
Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 0.1 " | 2.54 mm | Brass | Tin | 15.24 mm | 0.6 in | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 2 | 48 | 24 | |||
 Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 22 | 0.1 " | 2.54 mm | Brass | Tin | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 11 | 2 | 7.62 mm | 0.3 in | |||
 Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 24 | 0.1 " | 2.54 mm | Brass | Tin | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 2 | 12 | 0.4 in | ||||
 Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 28 | 0.1 " | 2.54 mm | Brass | Tin | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 7.62 mm | 0.3 in | |||||
 Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 14 | 0.1 " | 2.54 mm | Brass | Tin | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 7.62 mm | 0.3 in | |||||
Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 0.1 " | 2.54 mm | Brass | Tin | 15.24 mm | 0.6 in | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | ||||||
 Preci-Dip | 1 A | 12.95 mm | 0.51 " | UL94 V-0 | 10 mOhm | Wire Wrap | Gold | 24 | 0.1 " | 2.54 mm | Brass | Tin | DIP | Through Hole | -55 C | 125 °C | Open Frame | Beryllium Copper | 0.1 in | 2.54 mm | Flash | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 2 | 12 | 7.62 mm | 0.3 in |
