Q45UR3 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
Q45UR ANALOG SERIES: CONTROLLER
| Part | Material - Body | Voltage - Supply [Max] | Voltage - Supply [Min] | Shielding | Output Type | Termination Style | Indicator | Ingress Protection | Package / Case | Sensor Type | Sensing Distance [Min] | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Max] | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | Thermoplastic Polyester | 24 V | 15 VDC | Unshielded | Analog Current and Voltage | Connector | LED | IP67 NEMA 6P | Module | Ultrasonic | 1.969 " | 50 mm | 9.843 " | 250 mm | -25 °C | 70 °C |
BANNER ENGINEERING | Thermoplastic Polyester | 24 V | 15 VDC | Unshielded | Analog Current and Voltage | Connector | LED | IP67 NEMA 6P | Module | Ultrasonic | 1.969 " | 50 mm | 9.843 " | 250 mm | -25 °C | 70 °C |
BANNER ENGINEERING | Thermoplastic Polyester | 24 V | 12 VDC | Unshielded | NPN/PNP | Connector | LED | IP67 NEMA 6P | Module | Ultrasonic | 1.969 " | 50 mm | 9.843 " | 250 mm | -25 °C | 70 °C |
