951136 Series
Manufacturer: 3M (TC)
Beta
⌘K
CONN HEADER R/A 36POS 2MM
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish - Mating | Contact Finish - Post | Number of Positions Loaded | Contact Length - Post [x] | Contact Length - Post | Fastening Type | Contact Length - Mating | Contact Length - Mating | Insulation Height | Insulation Height | Termination | Contact Material | Contact Finish Thickness - Mating | Mounting Type | Pitch - Mating [x] | Pitch - Mating [x] | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Type | Contact Shape | Insulation Color | Insulation Material | Material Flammability Rating | Connector Type | Shrouding |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 3M (TC) | 1 çm | 39.4 çin | Gold | Tin | All | 0.11 in | 2.79 mm | Push-Pull | 4.4 mm | 0.173 in | 0.079 in | 2 mm | Solder | Copper Alloy | Flash | Through Hole Right Angle | 0.079 in | 2 mm | 1 | -55 °C | 125 °C | 36 | Male Pin | Square | Black | Thermoplastic | UL94 V-0 | Header | Unshrouded |
