9GA0612 Series

Catalog

FAN AXIAL 60X38MM 12VDC WIRE

Part	Voltage Range [Min]	Voltage Range [Max]	Current Rating (Amps)	Material - Frame	Lifetime @ Temp.	Material - Blade	Noise	Bearing Type	Static Pressure	Static Pressure	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Width [y]	Weight	Weight	Fan Type	Approval Agency	RPM	Size / Dimension [z]	Size / Dimension [x]	Termination	Power (Watts)	Air Flow	Air Flow	Operating Temperature [Max]	Operating Temperature [Min]	Features	Weight [custom]	Weight [custom]	Lifetime @ Temp.
Sanyo Denki America Inc. 9GA0612K1021	10.8 VDC	13.2 VDC	0.95 A	Plastic	Varies Based on Temperature	Plastic	59 dB(A)	Ball	597.8 Pa	2.4 in H2O	-20 ░C	70 °C	12 VDC	38 mm	130.18 g	0.287 lb	Tubeaxial	CSA TUV UL	14800 RPM	60 mm	60 mm	2 Wire Leads	11.4 W	53 CFM	1.48 mł/min
Sanyo Denki America Inc. 9GA0612G9D001	7 V	13.2 VDC	270 mA	Plastic	Varies Based on Temperature	Plastic	43 dB	Ball	64.8 Pa	0.26 in H2O	-20 ░C	60 °C	12 VDC	10 mm	35.38 g	0.078 lb	Tubeaxial	CSA TUV UL	6200 RPM	60 mm	60 mm	3 Wire Leads	3.24 W	21.9 CFM	0.613 m³/min	60 °C	-4 °F	Locked Rotor Sensor
Sanyo Denki America Inc. 9GA0612K1011	10.8 VDC	13.2 VDC	0.95 A	Plastic	Varies Based on Temperature	Plastic	59 dB(A)	Ball	597.8 Pa	2.4 in H2O	-20 ░C	70 °C	12 VDC	38 mm	130.18 g	0.287 lb	Tubeaxial	CSA TUV UL	14800 RPM	60 mm	60 mm	3 Wire Leads	11.4 W	53 CFM	1.48 mł/min			Locked Rotor Protection Speed Sensor (Tach)
Sanyo Denki America Inc. 9GA0612L702	6 VDC	13.8 VDC	30 mA	Plastic		Plastic	17 dB	Ball	17.9 Pa	0.072 in H2O	-20 ░C	70 °C	12 VDC	15 mm			Tubeaxial	CSA TUV UL	2800 RPM	60 mm	60 mm	2 Wire Leads	0.36 W	10.9 CFM	0.305 mł/min				0.111 lb	50.35 g
Sanyo Denki America Inc. 9GA0612P6S001	10.8 VDC	13.2 VDC	150 mA	Plastic		Plastic	36 dB	Ball	81.2 Pa	0.326 in H2O	-10 °C	70 °C	12 VDC	20 mm	69.85 g	0.154 lb	Tubeaxial	CSA TUV UL	5500 RPM	60 mm	60 mm	4 Wire Leads	1.8 W	24.7 CFM	0.692 m³/min			PWM Control Speed Sensor (Tach)			40000 Hrs
Sanyo Denki America Inc. 9GA0612H7D01	6 VDC	13.8 VDC	100 mA	Plastic	Varies Based on Temperature	Plastic	34 dB(A)	Ball	55.5 Pa	0.223 in H2O	-20 ░C	70 °C	12 VDC	15 mm			Tubeaxial	CSA TUV UL	4900 RPM	60 mm	60 mm	3 Wire Leads	1.2 W	19.7 CFM	0.552 m³/min			Locked Rotor Sensor	0.111 lb	50.35 g
Sanyo Denki America Inc. 9GA0612M6D001	10.8 VDC	13.2 VDC	50 mA	Plastic		Plastic	18 dB(A)	Ball	19.9 Pa	0.08 in H2O	-20 ░C	70 °C	12 VDC	20 mm			Tubeaxial	CSA TUV UL	2700 RPM	60 mm	60 mm	3 Wire Leads	600 mW	12 CFM	0.336 mł/min			Locked Rotor Sensor	0.156 lb	70.76 g
Sanyo Denki America Inc. 9GA0612P1H03	10.8 VDC	13.2 VDC	0.55 A	Plastic		Plastic	52 dB	Ball	374.6 Pa	1.504 in H2O	-20 ░C	70 °C	12 VDC	38 mm	130.18 g	0.287 lb	Tubeaxial	CSA TUV UL	11500 RPM	60 mm	60 mm	4 Wire Leads	6.6 W	40.6 CFM	1.14 m³/min			PWM Control Speed Sensor (Tach)			40000 Hrs
Sanyo Denki America Inc. 9GA0612H9002	7 V	13.8 VDC	140 mA	Plastic	Varies Based on Temperature	Plastic	37 dB	Ball	42.3 Pa	0.17 in H2O	-20 ░C	70 °C	12 VDC	10 mm	35.38 g	0.078 lb	Tubeaxial	CSA TUV UL	5000 RPM	60 mm	60 mm	2 Wire Leads	1.68 W	17.6 CFM	0.493 m³/min
Sanyo Denki America Inc. 9GA0612J1021	10.8 VDC	12.6 VDC	1.5 A	Plastic	Varies Based on Temperature	Plastic	63 dB	Ball	822 Pa	3.3 in H2O	-20 ░C	60 °C	12 VDC	38 mm	130.18 g	0.287 lb	Tubeaxial	CSA TUV UL	17500 RPM	60 mm	60 mm	2 Wire Leads	18 W	62 CFM	1.74 mł/min	60 °C	-4 °F
