SRP5030TA Series
Manufacturer: Bourns Inc.
Beta
⌘K
POWER INDUCTOR (SMD), 6.8 ΜH, 4 A, SHIELDED, 4.3 A, SRP5030TA SERIES
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Material - Core | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Shielding | Type | Q @ Freq | Inductance | Package / Case | Current Rating (Amps) | DC Resistance (DCR) [Max] | Ratings | Current - Saturation (Isat) | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Frequency - Self Resonant | Tolerance | Mounting Type | Inductance Frequency - Test | DC Resistance (DCR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | -40 C | 150 °C | Carbonyl Powder | 0.118 " | 3 mm | Shielded | Drum Core Wirewound | 15 100 kHz | 6.8 µH | Nonstandard | 4 A | 76.2 mOhm | AEC-Q200 | 4.3 A | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 19 MHz | 20 % | Surface Mount | 100 kHz | |
 Bourns Inc. | -40 C | 150 °C | Carbonyl Powder | 0.118 " | 3 mm | Shielded | Drum Core Wirewound | 15 100 kHz | 3.3 µH | Nonstandard | 5 A | AEC-Q200 | 8 A | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 30 MHz | 20 % | Surface Mount | 100 kHz | 38 mOhm | |
Bourns Inc. | -40 C | 150 °C | Carbonyl Powder | 0.118 " | 3 mm | Shielded | Drum Core Wirewound | 15 100 kHz | 5.6 µH | Nonstandard | AEC-Q200 | 4.5 A | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 21 MHz | 20 % | Surface Mount | 100 kHz | 63 mOhm | ||
 Bourns Inc. | -55 C | 150 °C | Carbonyl Powder | 0.118 " | 3 mm | Shielded | Drum Core Wirewound | 15 100 kHz | 3.6 µH | Nonstandard | 4.9 A | 54 mOhm | AEC-Q200 | 7 A | 5.3 mm | 0.205 " | 0.209 " | 5.2 mm | 29 MHz | 20 % | Surface Mount | 100 kHz | |
 Bourns Inc. | -40 C | 150 °C | Carbonyl Powder | 0.118 " | 3 mm | Shielded | Drum Core Wirewound | 5 100 kHz | 220 nH | Nonstandard | 15.5 A | AEC-Q200 | 21 A | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 155 MHz | 20 % | Surface Mount | 100 kHz | 4.4 mOhm |
