DCCM Series

Manufacturer: Cinch Connectivity Solutions

Catalog

D-SUB MICRO-D CONNECTORS 100P STRHT PCB CNTCT SCKT NICKEL PLATING

Part	Material Flammability Rating	Features	Termination	Current Rating (Amps)	Mounting Type	Shell Material, Finish	Contact Finish	Contact Type	Contact Finish Thickness	Contact Finish Thickness	Shell Size, Connector Layout [y]	Shell Size, Connector Layout [x]	Flange Feature	Connector Style	Connector Type	Number of Positions	Dielectric Material	Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Primary Material	Number of Rows [custom]	Type	1st Connector	Length	Length	Color	Number of Positions [custom]	2nd Connector	Backset Spacing	Backset Spacing	Length [x]	Length [x]
Cinch Connectivity Solutions DCCM100SBSPN	UL94 V-0	Shielded	Solder	3 A	Through Hole	Aluminum Alloy Electroless Nickel Plated	Gold	Signal	50 µin	1.27 µm	0.043 in	0.05 in	Female Screwlock Mating Side	D-Type Micro-D	Receptacle Female Sockets	100
Cinch Connectivity Solutions DCCM37SSBN-X2S	UL94 V-0			3 A	Panel Mount	Aluminum Alloy Electroless Nickel Plated	Gold	Signal			0.043 in	0.05 in	Housing/Shell (Unthreaded)	D-Type Micro-D	Receptacle Female Sockets	37	Diallyl Phthalate (DAP) Glass Filled	Copper Alloy	-55 C	135 °C	Metal	2
Cinch Connectivity Solutions DCCM31P6E5-36.0B							Gold		50 µin	1.27 µm													D-Type Micro-D	Male Pins Plug	91.44 cm	3 ft	Individual Multiple	31	Individual Wire Leads
Cinch Connectivity Solutions DCCM15PCBRP	UL94 V-0	Shielded	Solder	3 A	Right Angle Through Hole	Aluminum Alloy Yellow Chromate Plated Cadmium	Gold	Signal	50 µin	1.27 µm	0.043 in	0.05 in	Female Screwlock Mating Side	D-Type Micro-D	Plug Male Pins	15	Diallyl Phthalate (DAP) Glass Filled	Copper Alloy	-55 C	135 °C		2								0.13 in	3.3 mm
Cinch Connectivity Solutions DCCM51P6E5-18.0B							Gold		50 µin	1.27 µm						51							D-Type Micro-D	Male Pins Plug			Individual Multiple		Individual Wire Leads			457.2 mm	1.5 ft
Cinch Connectivity Solutions DCCM37P6E5-36.0BN							Gold		50 µin	1.27 µm						37							D-Type Micro-D	Male Pins Plug	91.44 cm	3 ft	Individual Multiple		Individual Wire Leads
Cinch Connectivity Solutions DCCM9P6E5-18.0BN							Gold		50 µin	1.27 µm						9							D-Type Micro-D	Male Pins Plug			Individual Multiple		Individual Wire Leads			457.2 mm	1.5 ft
Cinch Connectivity Solutions DCCM37SBSPN	UL94 V-0	Shielded	Solder	3 A	Through Hole	Aluminum Alloy Electroless Nickel Plated	Gold	Signal	50 µin	1.27 µm	0.043 in	0.05 in	Female Screwlock Mating Side	D-Type Micro-D	Receptacle Female Sockets	37	Diallyl Phthalate (DAP) Glass Filled	Copper Alloy	-55 C	135 °C		2
Cinch Connectivity Solutions DCCM100SCBRPN	UL94 V-0	Shielded	Solder	3 A	Right Angle Through Hole	Aluminum Alloy Electroless Nickel Plated	Gold	Signal	50 µin	1.27 µm	0.043 in	0.05 in	Female Screwlock Mating Side	D-Type Micro-D	Receptacle Female Sockets	100	Diallyl Phthalate (DAP) Glass Filled	Copper Alloy	-55 C	135 °C										0.2 in	5.08 mm
Cinch Connectivity Solutions DCCM100SSBN	UL94 V-0	Shielded		3 A	Panel Mount	Aluminum Alloy Electroless Nickel Plated	Gold	Signal	50 µin	1.27 µm	0.043 in	0.05 in		D-Type Micro-D	Receptacle Female Sockets	100
