HX Series
Manufacturer: Pulse Electronics
Beta
⌘K
AUDIO TRANSFORMERS / SIGNAL TRANSFORMERS 1500V 350UH 8MA 2%
| Part | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] [z] | Turns Ratio - Primary:Secondary | Inductance | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Transformer Type | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | 27.94 mm | 1.1 in | 7.54 mm | 0.297 in | 8.33 mm | 0.328 in | 1:1 | 350 µH | 85 °C | -40 C | Surface Mount | Power over Ethernet (PoE) | |
 Pulse Electronics | 0.698 " 17.73 mm | 0.48 in 12.19 mm | 0.285 " | 1:1 | 120 µH | 85 °C | -40 C | Surface Mount | LAN 10 Base-T | 7.24 mm |
