FA Series

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - LEADED 50V 33PF C0G 5% RAD LS:2.5MM AECQ200

...

Part	Mounting Type	Package / Case	Voltage - Rated	Applications	Lead Spacing	Lead Spacing	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Ratings	Temperature Coefficient	Lead Style	Capacitance	Height - Seated (Max)	Features
TDK Corporation FA18C0G1H330JNU06	Through Hole	Radial	50 VDC	Automotive	2.5 mm	0.098 in	5 %	0.217 "	5.5 mm	-55 C	125 °C	0.098 in	2.5 mm	4 mm	0.157 in	AEC-Q200	C0G NP0	Formed Leads	33 pF
TDK Corporation FA26X8R1E474KNU06	Through Hole	Radial	25 VDC	Automotive	5 mm	0.197 "	10 %	0.236 "		-55 C	150 °C	0.138 in	3.5 mm	5.5 mm	0.217 in	AEC-Q200	X8R	Formed Leads - Kinked	0.47 µF	6 mm	High Temperature
TDK Corporation FA28C0G2A391JNU00	Through Hole	Radial	100 V	Automotive	5 mm	0.197 "	5 %	0.217 "	5.5 mm	-55 C	125 °C	0.098 in	2.5 mm	4 mm	0.157 in	AEC-Q200	C0G NP0	Formed Leads - Kinked	390 pF
TDK Corporation FA18NP02A102JNU06	Through Hole	Radial	100 V	Automotive	2.5 mm	0.098 in	5 %	0.217 "	5.5 mm	-55 C	150 °C	0.098 in	2.5 mm	4 mm	0.157 in	AEC-Q200	C0G NP0	Formed Leads	0.001 µF		High Temperature
TDK Corporation FA26NP02W153JNU06	Through Hole	Radial	450 V	Automotive	5 mm	0.197 "	5 %	0.236 "		-55 C	150 °C	0.138 in	3.5 mm	5.5 mm	0.217 in	AEC-Q200	C0G NP0	Formed Leads - Kinked	15000 pF	6 mm	High Temperature
TDK Corporation FA18NP01H272JNU06	Through Hole	Radial	50 VDC	Automotive	2.5 mm	0.098 in	5 %	0.217 "	5.5 mm	-55 C	150 °C	0.098 in	2.5 mm	4 mm	0.157 in	AEC-Q200	C0G NP0	Formed Leads	2700 pF		High Temperature
TDK Corporation FA28NP02A271JNU06	Through Hole	Radial	100 V	Automotive	5 mm	0.197 "	5 %	0.217 "	5.5 mm	-55 C	150 °C	0.098 in	2.5 mm	4 mm	0.157 in	AEC-Q200	C0G NP0	Formed Leads - Kinked	270 pF		High Temperature
TDK Corporation FA16X8R1H474KNU06	Through Hole	Radial	50 VDC	Automotive	2.5 mm	0.098 in	10 %	0.236 "		-55 C	150 °C	0.138 in	3.5 mm	5.5 mm	0.217 in	AEC-Q200	X8R	Formed Leads	0.47 µF	6 mm	High Temperature
TDK Corporation FA26C0G2J222JNU06	Through Hole	Radial	630 V	Automotive	5 mm	0.197 "	5 %	0.236 "		-55 C	125 °C	0.138 in	3.5 mm	5.5 mm	0.217 in	AEC-Q200	C0G NP0	Formed Leads - Kinked	2200 pF	6 mm
TDK Corporation FA18X7R1H103KNU00	Through Hole	Radial	50 VDC	Automotive	2.5 mm	0.098 in	10 %	0.217 "	5.5 mm	-55 C	125 °C	0.098 in	2.5 mm	4 mm	0.157 in	AEC-Q200	X7R	Formed Leads - Kinked	10000 pF
