SIT5002 Series

Manufacturer: SiTime

Catalog

MEMS OSC VCTCXO SMD

Part	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Height - Seated (Max) [Max]	Height - Seated (Max)	Type	Package / Case	Mounting Type	Voltage - Supply	Frequency Stability	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Frequency	Base Resonator	Output	Current - Supply (Max) [Max]	Height - Seated (Max) [Max]	Function	Size / Dimension [y]	Current - Supply (Disable) (Max)
SiTime SIT5002AI-2E-18VQ-100.000000T	3.2	2.5	4-SMD	0.031 in	0.8 mm	VCTCXO	4-SMD No Lead	Surface Mount	1.8 V	5 ppm	85 °C	-40 C	2.5 mm	0.098 in	3.2 mm	0.126 "	100 MHz	MEMS	HCMOS LVCMOS	31 mA
SiTime SIT5002AI-GE-33VM-100.000000T	2.7	2.4	4-SMD	0.031 in	0.8 mm	VCTCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	85 °C	-40 C	2.4 mm	0.094 in	2.7 mm	0.106 in	100 MHz	MEMS	HCMOS LVCMOS	33 mA
SiTime SIT5002AC-8E-33N0-100.000000Y			4-SMD (7x5)	0.039 in		TCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	70 °C	-20 ░C	5 mm	0.197 "	7 mm	0.276 "	100 MHz	MEMS	HCMOS LVCMOS	33 mA	1 mm
SiTime SIT5002AI-8E-33VQ-156.253125T			4-SMD (7x5)	0.039 in		VCTCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	85 °C	-40 C	5 mm	0.197 "	7 mm	0.276 "	156.253125 MHz	MEMS	HCMOS LVCMOS	33 mA	1 mm
SiTime SIT5002AI-3E-33E0-125.000000T				0.031 in	0.8 mm	TCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	85 °C	-40 C		0.126 in	5 mm	0.197 in	125 MHz	MEMS	HCMOS LVCMOS	33 mA		Enable/Disable	3.2 mm
SiTime SIT5002AI-3E-33E0-163.840000T				0.031 in	0.8 mm	TCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	85 °C	-40 C		0.126 in	5 mm	0.197 in	163.84 MHz	MEMS	HCMOS LVCMOS	33 mA		Enable/Disable	3.2 mm
SiTime SIT5002AC-2E-33E0-90.316800Y	3.2	2.5	4-SMD	0.031 in	0.8 mm	TCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	70 °C	-20 ░C	2.5 mm	0.098 in	3.2 mm	0.126 "	90.3168 MHz	MEMS	HCMOS LVCMOS	33 mA		Enable/Disable
SiTime SIT5002AI-3E-18E0-163.840000T				0.031 in	0.8 mm	TCXO	4-SMD No Lead	Surface Mount	1.8 V	5 ppm	85 °C	-40 C		0.126 in	5 mm	0.197 in	163.84 MHz	MEMS	HCMOS LVCMOS	31 mA		Enable/Disable	3.2 mm	30 mA
SiTime SIT5002AC-8E-33VQ-125.000000T			4-SMD (7x5)	0.039 in		VCTCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	70 °C	-20 ░C	5 mm	0.197 "	7 mm	0.276 "	125 MHz	MEMS	HCMOS LVCMOS	33 mA	1 mm
SiTime SIT5002AI-2E-33VQ-156.250000T	3.2	2.5	4-SMD	0.031 in	0.8 mm	VCTCXO	4-SMD No Lead	Surface Mount	3.3 V	5 ppm	85 °C	-40 C	2.5 mm	0.098 in	3.2 mm	0.126 "	156.25 MHz	MEMS	HCMOS LVCMOS	33 mA
