29037 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE DPDT 16A 230V
| Part | Coil Resistance | Contact Material | Mounting Type | Load - Max Switching | Coil Current | Approval Agency | Coil Type | Termination Style | Release Time | Operating Temperature [Max] | Operating Temperature [Min] | Relay Type | Contact Form | Contact Rating (Current) | Operate Time | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 19.17 kOhms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 12 mA | CSA cURus EAC UR | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | DPDT (2 Form C) | 16 A | 25 ms | 230 VAC |
 Phoenix Contact | 207 Ohms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 116 mA | CSA cULus EAC UL | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | 3PST-NO (3 Form A) | 16 A | 25 ms | 24 VAC |
 Phoenix Contact | 19.17 kOhms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 12 mA | CSA cULus EAC UL | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | 3PDT (3 Form C) | 16 A | 25 ms | 230 VAC |
 Phoenix Contact | 5.22 kOhms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 23 mA | CSA cULus EAC UL | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | 3PST-NO (3 Form A) | 16 A | 25 ms | 120 VAC |
 Phoenix Contact | 207 Ohms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 116 mA | CSA cULus EAC UL | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | 3PDT (3 Form C) | 16 A | 25 ms | 24 VAC |
 Phoenix Contact | 19.17 kOhms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 12 mA | CSA cULus EAC UL | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | 3PST-NO (3 Form A) | 16 A | 25 ms | 230 VAC |
 Phoenix Contact | 5.22 kOhms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 23 mA | CSA cULus EAC UL | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | 3PDT (3 Form C) | 16 A | 25 ms | 120 VAC |
 Phoenix Contact | 343 Ohms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 70 mA | CSA cULus EAC UL | Non Latching | Plug In | 15 ms | 70 °C | -40 C | General Purpose | 3PST-NO (3 Form A) | 16 A | 20 ms | 24 VDC |
Phoenix Contact | 5.22 kOhms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 23 mA | CSA cURus EAC UR | Non Latching | Plug In | 20 ms | 55 °C | -40 C | General Purpose | DPDT (2 Form C) | 16 A | 25 ms | 120 VAC |
 Phoenix Contact | 429 Ohms | Silver Nickel (AgNi) | Socketable | 4000 W 7040 VA | 56 mA | CSA cULus EAC UL | Non Latching | Plug In | 15 ms | 70 °C | -40 C | General Purpose | 3PDT (3 Form C) | 16 A | 20 ms | 24 VDC |
