SS36 Series

Catalog

DIODE SCHOTTKY 60V 3A DO214AA

Part	Speed	Current - Average Rectified (Io)	Package / Case	Operating Temperature - Junction [Min]	Operating Temperature - Junction [Max]	Technology	Supplier Device Package	Current - Reverse Leakage @ Vr	Voltage - Forward (Vf) (Max) @ If	Mounting Type	Voltage - DC Reverse (Vr) (Max) [Max]
Comchip Technology SS36B-HF	200 mA 500 ns	3 A	DO-214AA SMB	-55 °C	150 °C	Schottky	DO-214AA (SMB)	500 µA	700 mV	Surface Mount	60 V
Comchip Technology SS36C-HF	200 mA 500 ns	3 A	DO-214AB SMC	-55 °C	150 °C	Schottky	DO-214AB (SMC)	500 µA	700 mV	Surface Mount	60 V
Comchip Technology SS36BF-HF	200 mA 500 ns	3 A	DO-221AA SMB Flat Leads	-55 °C	150 °C	Schottky	SMBF	500 µA	700 mV	Surface Mount	60 V
Comchip Technology SS36-HF	200 mA 500 ns	3 A	DO-214AC SMA	-55 °C	125 °C	Schottky	DO-214AC (SMA)	500 µA	700 mV	Surface Mount	60 V
