IRSM836 Series
Manufacturer: INFINEON
Beta
⌘K
500 V, CIPOS™ NANO 3 PHASE OPEN SOURCE INTELLIGENT POWER MODULE (IPM) WITH MOSFET IN PQFN 12X12 PACKAGE.
| Part | Features | Voltage - Supply [Max] | Voltage - Supply [Min] | Load Type | Fault Protection | Rds On (Typ) | Current - Peak Output | Output Configuration | Voltage - Load [Max] | Applications | Package / Case | Technology | Current - Output / Channel | Supplier Device Package | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Interface | Motor Type - AC, DC | Function | Current - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | Bootstrap Circuit | 16.5 V | 13.5 V | Inductive | UVLO | 4.8 Ohm | 7 A | Half Bridge (3) | 400 V | AC Motors | 36-PowerVQFN | UMOS | 1 A | 36-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Logic | |||
INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 200 V | Appliance | 36-PowerVQFN | UMOS | 36-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 2 A | ||||||
 INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 400 V | Appliance | 31-PowerVQFN | UMOS | 27-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 3 A | ||||||
 INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 200 V | Appliance | 36-PowerVQFN | UMOS | 36-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 4 A | ||||||
 INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 400 V | Appliance | 37-PowerVQFN | UMOS | 37-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 4 A | ||||||
INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 200 V | Appliance | 36-PowerVQFN | UMOS | 36-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 4 A | ||||||
INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 400 V | Appliance | 36-PowerVQFN | UMOS | 36-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 2 A | ||||||
 INFINEON | 16.5 V | 13.5 V | Half Bridge (3) | 200 V | Appliance | 36-PowerVQFN | UMOS | 36-PQFN (12x12) | -40 °C | 150 °C | Surface Mount | Parallel | AC Synchronous | Driver - Fully Integrated Control and Power Stage | 2 A |
