C6053AL Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
SWITCH ROCKER
| Part | Approval Agency | Current Rating (Amps) | Ingress Protection | Mounting Type | Termination Style | Illumination Type, Color [custom] | Illumination Type, Color [custom] | Actuator Type | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Color - Actuator/Cap | Circuit | Illumination Voltage (Nominal) | Actuator Marking | Switch Function | Voltage Rating - AC | Illumination Type, Color | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | ||||||||||||||||||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Neon | Green | Flat - Illuminated | 22.2 mm | 30.1 mm | Green | DPST | 125 VAC | O - | On-Off | 277 V | ||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Flat - Illuminated | 22.2 mm | 30.1 mm | Red | DPST | 250 VAC | No Marking | On-Off | 277 V | Neon Red | |||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Concave (Curved) | 22.2 mm | 30.1 mm | DPST | On-Off | 277 V | ||||||||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Neon | Green | Flat - Illuminated | 22.2 mm | 30.1 mm | Green | DPST | 250 VAC | O - | On-Off | 277 V | Antimicrobial | |
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Flat - Illuminated | 22.2 mm | 30.1 mm | Red | DPST | 125 VAC | No Marking | On-Off | 277 V | Neon Red | |||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Flat - Illuminated | 22.2 mm | 30.1 mm | Red | DPST | 250 VAC | O - | On-Off | 277 V | Neon Red | Antimicrobial | ||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Concave (Curved) | 22.2 mm | 30.1 mm | DPST | On-Off | 277 V | ||||||||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Flat - Illuminated | 22.2 mm | 30.1 mm | Red | DPST | 250 VAC | O - | On-Off | 277 V | Neon Red | |||
 BULGIN LIMITED | CSA ENEC UL | 20 A | Splash Proof | Panel Mount Snap-In | Quick Connect - 0.250" (6.3mm) | Flat - Illuminated | 22.2 mm | 30.1 mm | Red | DPST | 125 VAC | O - | On-Off | 277 V | Neon Red | Antimicrobial |
