171-050 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 50POS PNL MNT
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Color | Wire Gauge [Max] | Wire Gauge [Min] | Contact Form | Dielectric Material | Number of Rows [custom] | Mounting Type | Connector Type | Contact Finish Thickness | Connector Style | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish | Flange Feature | Material Flammability Rating | Contact Type | Features | Current Rating (Amps) | Termination | Contact Material | Shell Material, Finish | Shell Material, Finish [custom] | Shell Material, Finish [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 100 °C | -50 °C | Black | 28 AWG | 19.5 AWG | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount | Plug Male Pins | Flash | D-Sub | 50 | 5 | D DD | Gold | Cable Side (4-40) | UL94 V-0 | Signal | Grounding Indents | 5 A | |||||
NorComp Inc. | 100 °C | -50 °C | Black | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Housing/Shell (Unthreaded) | UL94 V-0 | Signal | 5 A | Solder | |||||||
 NorComp Inc. | 100 °C | -50 °C | Black | Stamped | Nylon 9T Polyamide (PA9T) | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Housing/Shell (Unthreaded) | UL94 V-0 | Signal | 5 A | Solder | Brass | Nickel Plated Steel | |||||
 NorComp Inc. | 100 °C | -50 °C | Black | Stamped | Nylon 9T Polyamide (PA9T) | 3 | Panel Mount Through Hole | Plug Male Pins | Flash | D-Sub | 50 | 5 | D DD | Gold | Board Side (4-40) Mating Side Female Screwlock (4-40) | UL94 V-0 | Signal | Board Lock Grounding Indents | 5 A | Solder | Brass | Nickel Plated Steel | ||||
 NorComp Inc. | 100 °C | -50 °C | Black | 28 AWG | 19.5 AWG | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Housing/Shell (Unthreaded) | UL94 V-0 | Signal | 5 A | ||||||
NorComp Inc. | 100 °C | -50 °C | Black | 28 AWG | 19.5 AWG | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Cable Side (4-40) | UL94 V-0 | Signal | 5 A | ||||||
 NorComp Inc. | 100 °C | -50 °C | Black | 28 AWG | 19.5 AWG | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Cable Side (4-40) | UL94 V-0 | Signal | 5 A | ||||||
NorComp Inc. | 100 °C | -50 °C | Black | 28 AWG | 19.5 AWG | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Cable Side (4-40) | UL94 V-0 | Signal | 5 A | Yellow Chromate Plated Zinc | Steel | ||||
NorComp Inc. | 100 °C | -50 °C | Black | Stamped | Polybutylene Terephthalate (PBT) | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Board Side (4-40) | UL94 V-0 | Signal | 5 A | Solder | |||||||
 NorComp Inc. | 100 °C | -50 °C | Black | Stamped | Nylon 9T Polyamide (PA9T) | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Flash | D-Sub | 50 | 5 | D DD | Gold | Board Side (4-40) | UL94 V-0 | Signal | 5 A | Solder | Brass | Nickel Plated Steel |
