PT04A Series

Catalog

PT 6C 6#20 PIN RECP

Part	Shell Material	Qualification	Backshell Material	Plating	Contact Material	Shell Finish	Insert Material	Fastening Type	Primary Material	Color	Contact Finish - Mating	Shielding	Applications	Termination	Operating Temperature (Max)	Operating Temperature (Min)	Orientation	Mounting Type	Number of Positions	Shell Size - Insert Length	Shell Size - Insert Width	Connector Type	Backshell Material, Plating
Amphenol Aerospace Operations PT04A-10-6P(027)	Aluminum	MIL-DTL-26482 Series I	Aluminum	Black Zinc Cobalt	Copper Alloy	Black Zinc Cobalt	Neoprene	Bayonet Lock	Metal	Black	Gold	Unshielded	Aerospace Industrial Instrumentation Mass Transit Military	Solder Cup	125 °C	-55 °C	N (Normal)	Free Hanging (In-Line)	6	10 mm	6 mm	Male Pins Receptacle
Amphenol Aerospace Operations PT04A8-4SW	Aluminum	MIL-DTL-26482 Series I			Copper Alloy	Cadmium Olive Drab Chromate	Neoprene	Bayonet Lock	Metal	Olive Drab	Gold	Unshielded	Aerospace Communication Systems Industrial Instrumentation Mass Transit	Solder Cup	125 °C	-55 °C	W	Free Hanging (In-Line)	4	8 mm	4 mm	Female Sockets Receptacle	Aluminum Olive Drab Cadmium
Amphenol Aerospace Operations PT04A12-10S-025	Aluminum	MIL-DTL-26482 Series I	Aluminum	Black Zinc Cobalt	Copper Alloy	Black Zinc Cobalt	Neoprene	Bayonet Lock	Metal	Black	Gold	Unshielded	Aerospace Communication Systems Industrial Instrumentation Mass Transit	Solder Cup	125 °C	-55 °C	N (Normal)	Free Hanging (In-Line)	10	12 mm	10 mm	Female Sockets Receptacle
