FC4L Series
Manufacturer: Ohmite
Beta
⌘K
SMD CURRENT SENSE RESISTORS, FC4L SERIES, 0.001 OHM, 2 W, - 5%, 2512 [6432 METRIC] ROHS COMPLIANT: YES
| Part | Supplier Device Package | Features | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Number of Terminations | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Power (Watts) | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Resistance | Tolerance | Temperature Coefficient | Size / Dimension [x] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Ohmite | 6432 | Current Sense Moisture Resistant | 155 C | -55 C | 1225 Wide 2512 (6432 Metric) | 4 | 6.4 mm | 0.252 in | 0.126 in | 3.2 mm | 2 W | 0.7 mm | 0.028 " | 1 mOhms | 5 % | 100 ppm/°C | ||
 Ohmite | 1206 | Current Sense Moisture Resistant | 155 C | -55 C | 0612 Wide 1206 (3216 Metric) | 4 | 3.2 mm | 1.6 mm | 1 W | 0.7 mm | 0.028 " | 1 mOhms | 5 % | 100 ppm/°C | 0.063 " | 0.126 in | ||
Ohmite | 11050 | Current Sense Moisture Resistant | 155 C | -55 C | 2043 Wide 4320 (11050 Metric) | 4 | 11 mm | 5 mm | 5 W | 0.7 mm | 0.028 " | 3 mOhms | 1 % | 50 ppm/░C | 0.197 in | 0.433 in | ||
Ohmite | 6432 | Current Sense Moisture Resistant | 155 C | -55 C | 1225 Wide 2512 (6432 Metric) | 4 | 6.4 mm | 0.252 in | 0.126 in | 3.2 mm | 2 W | 0.7 mm | 0.028 " | 15 mOhms | 1 % | 50 ppm/░C |
