408-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DL FMALE 35P 0.200 2PC
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness | Card Thickness | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Contact Finish | Pitch | Pitch | Number of Positions | Color | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Features | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Material | Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2.36 mm | 0.093 " | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | Card Guides | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 1.57 mm | 0.062 in | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2.36 mm | 0.093 " | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | Card Guides | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2.36 mm | 0.093 " | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | Card Guides | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2.36 mm | 0.093 " | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 1.57 mm | 0.062 in | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 1.57 mm | 0.062 in | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 1.57 mm | 0.062 in | Wire Wrap | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2.36 mm | 0.093 " | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 1.57 mm | 0.062 in | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Gold | 5.08 mm | 0.2 in | 35 | Green | -65 ░C | 125 °C | Panel Mount Through Hole | Card Guides | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female |
