AA10S Series

Catalog

AC/DC CONVERTER 15V 10W

Part	Line Regulation	Weight	Weight	Load Regulation	Mounting Type	Features	Applications	Efficiency	Standard Number	Approval Agency	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Type	Current - Output (Max) [Max]	Number of Outputs	Power (Watts)	Voltage - Output 1
Delta Electronics AA10S1500A	0.5 %	53.98 g	0.119 lb	0.5 %	Through Hole	Universal Input	ITE (Commercial)	75 %	60950-1	CE UL	0.93 "	1.07 in	2.06 "	52.3 mm	23.5 mm	27.2 mm	4-DIP Module	70 °C	-25 °C	Enclosed	667 mA	1	10 W	15 V
Delta Electronics AA10S0300A	0.5 %	53.98 g	0.119 lb	0.5 %	Through Hole	Universal Input	ITE (Commercial)	70 %	60950-1	CE UL	0.93 "	1.07 in	2.06 "	52.3 mm	23.5 mm	27.2 mm	4-DIP Module	70 °C	-25 °C	Enclosed	2.5 A	1	10 W	3.3 V
Delta Electronics AA10S2400A	0.5 %	53.98 g	0.119 lb	0.5 %	Through Hole	Universal Input	ITE (Commercial)	72 %	60950-1	CE UL	0.93 "	1.07 in	2.06 "	52.3 mm	23.5 mm	27.2 mm	4-DIP Module	70 °C	-25 °C	Enclosed		1	10 W	24 V
Delta Electronics AA10S1200A	0.5 %	53.98 g	0.119 lb	0.5 %	Through Hole	Universal Input	ITE (Commercial)	76 %	60950-1	CE UL	0.93 "	1.07 in	2.06 "	52.3 mm	23.5 mm	27.2 mm	4-DIP Module	70 °C	-25 °C	Enclosed	833 mA	1	10 W	12 V
