845-144 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 144POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Termination | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Color | Contact Material | Contact Finish | Pitch | Pitch | Number of Positions/Bay/Row [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions | Card Type | Gender | Features | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Through Hole | 3.25 mm | 0.128 " | 144 | Non Specified - Dual Edge | Female | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Wire Wrap | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Through Hole | 3.25 mm | 0.128 " | 144 | Non Specified - Dual Edge | Female | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Board Edge Straddle Mount | 144 | Non Specified - Dual Edge | Female | Card Extender | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder Eyelet(s) | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Through Hole | 3.96 mm | 0.156 " | 144 | Non Specified - Dual Edge | Female | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Through Hole | 3.25 mm | 0.128 " | 144 | Non Specified - Dual Edge | Female | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Right Angle Through Hole | 2.95 mm | 0.116 " | 144 | Non Specified - Dual Edge | Female | Floating Bobbin Flush Mount | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Board Edge Straddle Mount | 144 | Non Specified - Dual Edge | Female | Card Extender | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Wire Wrap | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Through Hole | 3.96 mm | 0.156 " | 144 | Non Specified - Dual Edge | Female | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Through Hole | 2.95 mm | 0.116 " | 144 | Non Specified - Dual Edge | Female | Floating Bobbin Flush Mount | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Solder | Dual | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Green | Copper Alloy | Gold | 0.1 " | 2.54 mm | 72 | 0.25 Ám | 10 Áin | 2 | Board Edge Straddle Mount | 144 | Non Specified - Dual Edge | Female | Card Extender | 4-40 Threaded Insert Top Mount Opening |
