RJE01 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN MOD JACK 6P6C R/A UNSHLD
| Part | Contact Finish Thickness | Contact Finish Thickness | Housing Material | Operating Temperature [Min] | Operating Temperature [Max] | Features | Shielding | Contact Material | Connector Type | Number of Positions/Contacts [y] | Number of Positions/Contacts [x] | LED Color | Termination | Number of Rows | Number of Ports | Contact Finish | Orientation | Tab Direction | Mounting Type | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | 0.38 µm | 15 µin | Thermoplastic | -55 C | 85 °C | Board Lock | Unshielded | Phosphor Bronze | Jack | 6 | 6 | Does Not Contain LED | Solder | 1 | 2 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | Polyamide (PA) Nylon | -55 C | 85 °C | Board Lock | EMI Finger Shielded | Phosphor Bronze | Jack | 6 | 6 | Does Not Contain LED | Solder | 1 | 2 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | Thermoplastic | -55 C | 85 °C | Board Lock | Unshielded | Phosphor Bronze | Jack | 4 | 6 | Does Not Contain LED | Solder | 1 | 2 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | Polyamide (PA) Nylon | -55 C | 85 °C | Board Lock | EMI Finger Shielded | Phosphor Bronze | Jack | 6 | 6 | Does Not Contain LED | Solder | 1 | 2 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | Thermoplastic | -55 C | 85 °C | Board Lock | EMI Finger Shielded | Phosphor Bronze | Jack | 6 | 6 | Does Not Contain LED | Solder | 1 | 1 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | Thermoplastic | -55 C | 85 °C | Board Lock | EMI Finger Shielded | Phosphor Bronze | Jack | Does Not Contain LED | Solder | 1 | 1 | Gold | 90 ° | Up | Through Hole | 6 | 2 | ||
Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | Thermoplastic | -55 C | 85 °C | Board Lock | Shielded | Phosphor Bronze | Jack | 4 | 6 | Does Not Contain LED | Solder | 1 | 1 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | Polyamide (PA) Nylon | -55 C | 85 °C | Board Lock | Unshielded | Phosphor Bronze | Jack | 6 | 6 | Does Not Contain LED | Solder | 1 | 1 | Gold | 90 ° | Up | Through Hole | ||
Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | Thermoplastic | -55 C | 85 °C | Board Lock | Unshielded | Phosphor Bronze | Jack | 6 | 6 | Does Not Contain LED | Solder | 1 | 2 | Gold | 90 ° | Up | Through Hole | ||
 Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | Thermoplastic | 0 °C | 70 °C | Board Lock | Unshielded | Phosphor Bronze | Jack | 4 | 6 | Does Not Contain LED | Solder | 1 | 2 | Gold | 90 ° | Up | Through Hole |
