GK0YBR-P Series
Manufacturer: ODU
Beta
⌘K
ODU AMC RECEPT, STY K, SZ 0, 10P
| Part | Voltage Rating | Mounting Feature | Insert Material | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Shielding | Material Flammability Rating | Fastening Type | Termination | Mounting Type | Shell Size - Insert [custom] | Contact Material | Color | Shell Material | Contact Finish - Mating | Shell Finish | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Ingress Protection | Connector Type | Current Rating (Amps) | Primary Material | Orientation | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
200 V | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 10 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Solder | Panel Mount Through Hole | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 5 A | Metal | B | Industrial Medical Military | |
200 V | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 9 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Solder | Panel Mount Through Hole | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 5 A | Metal | B | Industrial Medical Military | |
300 VDC | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 4 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Solder | Panel Mount Through Hole | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 5 A | Metal | B | Industrial Medical Military | |
400 V | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Panel Mount | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 10 A | Metal | B | Industrial Medical Military | |||
300 VDC | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 4 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Panel Mount | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 7 A | Metal | B | Industrial Medical Military | ||
300 VDC | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 7 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Panel Mount | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 5 A | Metal | B | Industrial Medical Military | ||
200 V | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 9 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Panel Mount | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 5 A | Metal | B | Industrial Medical Military | ||
200 V | Bulkhead - Front Side Nut | Polyetheretherketone (PEEK) | 10 | -51 °C | 125 °C | Shielded | UL94 V-0 | Detent Lock Push-Pull | Panel Mount | 0 | Copper Alloy | Silver | Aluminum | Gold | Ruthenium over Electroless Nickel | 50 µin | 1.27 µm | IP68 IP69K | Receptacle Female Sockets | 5 A | Metal | B | Industrial Medical Military |
