Side view RGB Chip LED
Description
AI
MSL01 series is a reflector type side-emitting RGB chip LED. Its large aperture makes it ideal for connecting with a light guide plate and illuminating a wide area.
Beta
⌘K
Side view RGB Chip LED
Side view RGB Chip LED
| Part | Configuration | Wavelength - Dominant [custom] | Wavelength - Dominant [custom] | Wavelength - Dominant [custom] | Height (Max) [Max] [z] | Millicandela Rating [custom] | Millicandela Rating [custom] | Millicandela Rating [custom] | Voltage - Forward (Vf) (Typ) | Mounting Type | Supplier Device Package | Supplier Device Package | Package / Case | Lens Color | Lens Style | Size / Dimension [y] | Size / Dimension [x] | Lens Transparency | Lens Size [x] | Lens Size [y] | Current - Test | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | Independent | 470 nm | 624 nm | 527 nm | 2.15 mm | 700 mcd | 1200 mcd | 400 mcd | 2.1 V 3.2 V 3.3 V | Right Angle Surface Mount | 6922 Metric | 2709 | 7-SMD Flat Lead | White | Rectangle with Flat Top | 2.2 mm | 6.9 mm | Diffused | 5.4 mm | 1.6 mm | 20mA Blue 20mA Green 20mA Red | Blue Green Red |
