6010 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
AC POWER ENTRY MODULES 6010 APPLIANCE INLET 10A 70C
| Part | Material Flammability Rating | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Termination | Termination | Termination | Voltage Rating - Appliance Inlet | Connector Style | Current Rating - Appliance Inlet | Connector Type | Approval Agency | Mounting Type | Accomodates a Fuse | Ingress Protection | Filter Type | Panel Thickness | Panel Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | UL94 V-0 | 27.5 mm | 20 mm | 6.3 mm | Quick Connect | 0.25 " | 250 VAC | IEC 320-C14 | 10 A | Receptacle Male Blades | CCC cCSAus ENEC UL | Panel Mount Snap-In | IP20 | Unfiltered - Commercial | 0.079 in | 2 mm | |
 SCHURTER Inc. | UL94 V-0 | 27.5 mm | 20 mm | Solder Eyelet | 250 VAC | IEC 320-C14 | 10 A | Receptacle Male Blades | CCC cCSAus ENEC UL | Panel Mount Snap-In | IP20 | Unfiltered - Commercial | 0.098 in | 2.5 mm |
