FS1A474 Series
Manufacturer: KEMET
Beta
⌘K
CAP SUPERCAP 0.47F 11V -20% TO 80% ( 28.5 X 25.5MM ) RADIAL CYLINDRICAL 10.16MM 7 OHM 1000H 70°C BOX
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [diameter] | Size / Dimension [diameter] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Mounting Type | Voltage - Rated | Capacitance | Lead Spacing | Lead Spacing | Tolerance [Max] | Tolerance [Min] | Termination | ESR (Equivalent Series Resistance) | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | -25 °C | 70 °C | 28.5 mm | 1.122 in | 1.004 in | 25.5 mm | Through Hole | 11 V | 470 mF | 0.4 " | 10.16 mm | 80 % | -20 % | PC Pins | 7 Ohm | Can Radial |
