CHS60483 Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
DC-DC CONVERTER, 3.3V, 18A ROHS COMPLIANT: YES
| Part | Efficiency | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Output 1 | Type | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Current - Output (Max) [Max] | Size / Dimension [y] | Size / Dimension | Size / Dimension [x] | Size / Dimension [z] | Power (Watts) | Voltage - Isolation | Applications | Number of Outputs | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | 91.5 % | Through Hole | -40 °C | 85 °C | 3.3 V | Isolated Module | 76 V | 36 V | 18 A | 0.75 in | 12.7 mm 19.1 mm 23.4 mm | 0.92 " | 0.5 in | 59 W | 250 V | ITE (Commercial) | 1 | 8-DIP Module |
