HiperLCS Series

Catalog

GATE DRIVERS 220W HV CONTROLLER MOSFET

Part	Technology	Load Type	Rds On (Typ)	Current - Peak Output	Features	Operating Temperature [Min]	Operating Temperature [Max]	Fault Protection	Voltage - Load [Max]	Voltage - Load [Min]	Mounting Type	Interface	Package / Case	Applications	Voltage - Supply [Min]	Voltage - Supply [Max]	Supplier Device Package
POWER INTEGRATIONS LCS702HG	Power MOSFET	Inductive	740 mOhm	10.3 A	Auto Restart Slew Rate Controlled	-40 °C	150 °C	Current Limiting Over Temperature Over Voltage Short Circuit UVLO	15 V	11.4 V	Through Hole	On/Off	16-SSIP 13 Leads Exposed Pad Formed Leads	General Purpose	11.4 V	15 V
POWER INTEGRATIONS LCS705HG	Power MOSFET	Inductive	400 mOhm	19.3 A	Auto Restart Slew Rate Controlled	-40 °C	150 °C	Current Limiting Over Temperature Over Voltage Short Circuit UVLO	15 V	11.4 V	Through Hole	On/Off	16-SSIP 13 Leads Exposed Pad Formed Leads	General Purpose	11.4 V	15 V
POWER INTEGRATIONS LCS701LG	Power MOSFET	Inductive	1 Ohm	7.7 A	Auto Restart Slew Rate Controlled	-40 °C	150 °C	Current Limiting Over Temperature Over Voltage Short Circuit UVLO	15 V	11.4 V	Through Hole	On/Off	16-SSIP 13 Leads Exposed Pad Formed Leads	General Purpose	11.4 V	15 V	eSIP-16K
