TSPC Series
Manufacturer: Phoenix Contact
Beta
⌘K
PLUGGABLE TERMINAL BLOCKS 8 POS 7.62MM PITCH PLUG 24-8 AWG SPRING
| Part | Insulation Height | Insulation Height | Wire Strip Length | Housing Material | Material Flammability Rating | Mounting Type | Plug Wire Entry | Type | Current - IEC | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] | Current - UL | Contact Mating Finish | Number of Levels [custom] | Number of Levels [custom] | Pitch | Pitch | Voltage - IEC | Color | Number of Positions | Wire Gauge or Range - mm² [Max] | Wire Gauge or Range - mm² [Min] | Positions Per Level [custom] | Positions Per Level [custom] | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 35.05 mm | 1.38 in | 15 mm | Polyamide (PA) Nylon | UL94 V-0 | Free Hanging (In-Line) | 180 ° | Plug Female Sockets | 41 A | 24 AWG | 8 AWG | 31 A | Tin | 1 | 2 | 0.3 in | 7.62 mm | 1 kV | Green | 8 | 10 mm² | 0.2 mm² | 16 | 8 | Screwless - Push-In Spring |
