MD801-009 Series
Manufacturer: Cinch Connectivity Solutions
Beta
⌘K
MINIATURE D38999 CIRCULAR CONNEC
| Part | Shell Finish | Orientation | Connector Type | Number of Positions | Shell Size - Insert [Min] | Shell Size - Insert [Max] | Current Rating (Amps) | Termination | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Shell Material | Shielding | Mounting Type | Ingress Protection | Fastening Type | Mounting Feature | Color | Cable Opening | Cable Opening | Primary Material | Shell Size - Insert |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cinch Connectivity Solutions | Olive Drab Chromate over Cadmium | F | Receptacle Male Pins | 37 | 13 | 37 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Olive Drab | ||||
Cinch Connectivity Solutions | Electroless Nickel | D | Receptacle Female Sockets | 37 | 13 | 37 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Silver | ||||
Cinch Connectivity Solutions | Electroless Nickel | B | Receptacle Male Pins | 26 | 10 | 26 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Silver | ||||
 Cinch Connectivity Solutions | Electroless Nickel | F | Receptacle Male Pins | 10 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Silver | 9.91 mm | 0.39 in | Metal | |||
 Cinch Connectivity Solutions | Electroless Nickel | A | Receptacle Male Pins | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Silver | 16.5 mm | 0.65 in | Metal | 13-3 | |||
Cinch Connectivity Solutions | Olive Drab Chromate over Cadmium | E | Receptacle Male Pins | 13 | 8 | 13 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Olive Drab | ||||
Cinch Connectivity Solutions | Olive Drab Chromate over Cadmium | B | Receptacle Male Pins | 19 | 9 | 19 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Olive Drab | ||||
 Cinch Connectivity Solutions | Olive Drab Chromate over Cadmium | E | Receptacle Male Pins | 2 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Olive Drab | 16.5 mm | 0.65 in | Metal | 13-2 | ||
Cinch Connectivity Solutions | Olive Drab Chromate over Cadmium | D | Receptacle Female Sockets | 7 | 6 | 7 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Olive Drab | ||||
Cinch Connectivity Solutions | Electroless Nickel | F | Receptacle Female Sockets | 4 | 5 A | Crimp | Aerospace Military | -65 ░C | 175 °C | Aluminum | Shielded | Panel Mount | IP67 - Dust Tight Waterproof | Threaded | Bulkhead - Front Side Nut | Silver | 7.37 mm | 0.29 in | Metal | 6-4 |
