Fixed Terminal Blocks SMKDS 5/ 3-6 35 Z1L BD:1-3
Fixed Terminal Blocks SMKDS 5/ 3-6 35 Z1L BD:1-3
| Part | Number of Levels | Voltage | Color | Wire Gauge [Min] | Wire Gauge [Max] | Current | Positions Per Level | Wire Termination | Mounting Type | Mating Orientation | Mating Orientation | Pitch | Pitch | Mating Orientation | Features | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Torque - Screw [Max] | Housing Material | Screw Thread | Positions Per Level [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 1 | 300 VDC | Green | 16 AWG | 30 AWG | 10 A | 4 | Screw - Rising Cage Clamp | Through Hole | 55 ° | 125 ° | 3.81 mm | 0.15 in | |||||||||
 Phoenix Contact | 1 | 300 VDC | Green | 12 AWG | 30 AWG | 15 A | 3 | Screw - Rising Cage Clamp | Through Hole | 5.08 mm | 0.2 in | 35° (145°) Angle with Board | Interlocking (Side) | |||||||||
 Phoenix Contact | 1 | 630 V | Green | 32 A | 3 | Screw - Rising Cage Clamp | Through Hole | 6.35 mm | 0.25 in | 35° (145°) Angle with Board | Interlocking (Side) Positions Stamped | |||||||||||
 Phoenix Contact | 1 | 300 VDC | Green | 10 AWG | 30 AWG | 30 A | 3 | Screw - Rising Cage Clamp | Through Hole | 6.35 mm | 0.25 in | 35° (145°) Angle with Board | Interlocking (Side) | 0.6 Nm | 4.4 Lb-In | 0.5 Nm | 5.3 Lb-In | Polyamide (PA) Nylon | M3 | |||
 Phoenix Contact | 1 | 300 VDC | Green | 16 AWG | 30 AWG | 10 A | 2 | Screw - Rising Cage Clamp | Through Hole | 55 ° | 125 ° | 3.81 mm | 0.15 in | |||||||||
 Phoenix Contact | 1 | 300 VDC | Green | 16 AWG | 30 AWG | 10 A | Screw - Rising Cage Clamp | Through Hole | 55 ° | 125 ° | 3.5 mm | 0.138 " | 0.25 Nm | 1.9 Lb-In | 0.22 Nm | 2.2 Lb-In | Polyamide (PA) Nylon | M2 | 7 | |||
 Phoenix Contact | 1 | 300 VDC | Green | 16 AWG | 30 AWG | 10 A | 11 | Screw - Rising Cage Clamp | Through Hole | 55 ° | 125 ° | 3.5 mm | 0.138 " |
