333-039 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 39POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Finish | Gender | Termination | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions/Bay/Row | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Contact Type | Number of Rows | Number of Positions | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Solder | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Green | Cantilever | 1 | 39 | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Solder | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | 4-40 Threaded Insert Top Mount Opening | Green | Cantilever | 1 | 39 | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Green | Cantilever | 1 | 39 | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Green | Cantilever | 1 | 39 | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Solder Eyelet(s) | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Green | Cantilever | 1 | 39 | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Solder | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | 4-40 Flush Mount Threaded Insert Top Opening | Green | Cantilever | 1 | 39 | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Green | Cantilever | 1 | 39 | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | 0.128 " | 3.25 mm | Green | Cantilever | 1 | 39 | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Solder | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | 4-40 Flush Mount Threaded Insert Top Opening | Green | Cantilever | 1 | 39 | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Female | Solder | Copper Alloy | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 39 | Single | Flush Mount M3 Threaded Insert Top Opening | Green | Cantilever | 1 | 39 | Right Angle Through Hole |
