SDF-R15 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 15POS R/A SLDR
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Color | Contact Material | Dielectric Material | Shell Material, Finish | Termination | Contact Type | Material Flammability Rating | Flange Feature | Number of Positions | Contact Finish Thickness | Contact Finish | Ingress Protection | Mounting Type | Current Rating (Amps) | Shell Size, Connector Layout | Connector Type | Features | Connector Style | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Flash | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Receptacle Female Sockets | Board Lock Mounting Brackets | D-Sub | 2 | ||
 NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Plug Male Pins | Grounding Indents | D-Sub | 2 | 30 Áin | 0.76 Ám | |
 NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Flash | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Receptacle Female Sockets | D-Sub | 2 | |||
 NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Plug Male Pins | Board Lock Grounding Indents Mounting Brackets | D-Sub | 2 | 30 Áin | 0.76 Ám | |
NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Flash | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Plug Male Pins | Board Lock Grounding Indents Mounting Brackets | D-Sub | 2 | ||
 NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Receptacle Female Sockets | Board Lock Mounting Brackets | D-Sub | 2 | 30 Áin | 0.76 Ám | |
 NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Receptacle Female Sockets | D-Sub | 2 | 30 Áin | 0.76 Ám | ||
NorComp Inc. | 85 °C | -25 °C | Black | Brass | Polybutylene Terephthalate (PBT) | Nickel Plated Steel | Solder | Signal | UL94 V-0 | 4-40 Mating Side Female Screwlock | 15 | Flash | Gold | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | 5 A | 2 | Plug Male Pins | Grounding Indents | D-Sub | 2 |
