TXU0202 Series
Manufacturer: Texas Instruments
Beta
⌘K
TWO CHANNEL FIXED-DIRECTION LEVEL SHIFTER WITH CHANNELS IN OPPOSITE DIRECTION
| Part | Channel Type | Voltage - VCCB [Max] | Voltage - VCCB [Min] | Translator Type | Channels per Circuit | Package / Case | Number of Circuits | Supplier Device Package | Supplier Device Package [x] | Supplier Device Package [y] | Output Type | Data Rate | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - VCCA [Min] | Voltage - VCCA [Max] | Package / Case [custom] | Package / Case [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Bidirectional Unidirectional | 5.5 V | 1.08 V | Voltage Level | 2 | 8-XFDFN Exposed Pad | 1 | 8-X2SON | 1.35 | 0.8 | Non-Inverted Tri-State | 200 Mbps | Surface Mount | 125 °C | -40 °C | 1.08 V | 5.5 V | ||
 Texas Instruments | Bidirectional Unidirectional | 5.5 V | 1.08 V | Voltage Level | 2 | 8-XFDFN Exposed Pad | 1 | 8-X1SON | 1.95 | 1 | Tri-State | 200 Mbps | Surface Mount | 125 °C | -40 °C | 1.08 V | 5.5 V | ||
 Texas Instruments | Bidirectional Unidirectional | 5.5 V | 1.08 V | Voltage Level | 2 | 8-VFSOP | 1 | 8-VSSOP | Non-Inverted Tri-State | 200 Mbps | Surface Mount | 125 °C | -40 °C | 1.08 V | 5.5 V | 2.3 mm | 0.091 " |
