3SB2202 Series

Manufacturer: Siemens

Catalog

PUSHBUTTON,MOMENTARY,RINGS,YLW,N

Part	Mechanical Life	Panel Cutout Dimensions [diameter]	Voltage Rating - DC	Actuator Type	Voltage Rating - AC	Termination Style	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Type	Ingress Protection	Circuit	Current Rating (Amps)	Switch Function	Color - Actuator/Cap	Approval Agency	Depth Behind Flange	Number of Positions	Illumination
Siemens 3SB22020AD01	10000000 Cycles	16 mm	24 V	Button Flush Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	Yellow
Siemens 3SB22022AB01	300000 Cycles	16 mm	24 V		110 V	Quick Connect	-25 °C	70 °C	Panel Mount	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-On		CCC CE CSA EAC UL	50 mm	2	Non-Illuminated
Siemens 3SB22020AB01	10000000 Cycles	16 mm	24 V	Button Flush Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	Black
Siemens 3SB22022AE01	300000 Cycles	16 mm	24 V		110 V	Quick Connect	-25 °C	70 °C	Panel Mount	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-On		CCC CE CSA EAC UL	50 mm	2	Non-Illuminated
Siemens 3SB22020LH01	10000000 Cycles	16 mm	24 V	Button Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	Clear
Siemens 3SB22020LD01	10000000 Cycles	16 mm	24 V	Button Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	Yellow
Siemens 3SB22020AF01	10000000 Cycles	16 mm	24 V	Button Flush Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	Blue
Siemens 3SB22022AG01	300000 Cycles	16 mm	24 V		110 V	Quick Connect	-25 °C	70 °C	Panel Mount	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-On		CCC CE CSA EAC UL	50 mm	2	Non-Illuminated
Siemens 3SB22020AG01	10000000 Cycles	16 mm	24 V	Button Flush Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	White
Siemens 3SB22020LB01	10000000 Cycles	16 mm	24 V	Button Round	110 V	Quick Connect	-25 °C	70 °C	Panel Mount Front	Standard	IP65 - Dust Tight Water Resistant	SPST-NO	6 A 10 A	Off-Mom	Black
