R1172 Series

Manufacturer: Nisshinbo Micro Devices Inc.

Catalog

IC REG LINEAR 1.5V 1A 6HSOP

Part	Voltage Dropout (Max)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output (Min/Fixed)	Current - Output	PSRR	Number of Regulators	Output Configuration	Supplier Device Package	Control Features	Package / Case	Package / Case	Protection Features	Current - Quiescent (Iq)	Voltage - Input (Max) [Max]	Mounting Type	Supplier Device Package [y]	Supplier Device Package [x]	Voltage Dropout (Max) [Max]	Voltage - Output (Min/Fixed) [Min]
Nisshinbo Micro Devices Inc. R1172S151D-E2-FE	0.32 V	85 °C	-40 C	1.5 V	1 A	70 db	1	Positive	6-HSOP-J	Enable	0.154 in 3.9 mm	4 Leads + 2 Fins 6-SOIC Variation	Over Current Over Temperature	100 µA	6 V	Surface Mount
Nisshinbo Micro Devices Inc. R1172D311D-TR-FE	0.18 V	85 °C	-40 C	3.1 V	1 A	70 db	1	Positive	6-HSON	Enable		6-SMD Flat Leads Exposed Pad	Over Current Over Temperature	100 µA	6 V	Surface Mount	2.8	2.9
Nisshinbo Micro Devices Inc. R1172D121A-TR-FE		85 °C	-40 C	1.2 V	1 A	70 db	1	Positive	6-HSON	Enable		6-SMD Flat Leads Exposed Pad	Over Current Over Temperature	100 µA	6 V	Surface Mount	2.8	2.9	0.56 V
Nisshinbo Micro Devices Inc. R1172S251D-E2-FE	0.32 V	85 °C	-40 C	2.5 V	1 A	70 db	1	Positive	6-HSOP-J	Enable	0.154 in 3.9 mm	4 Leads + 2 Fins 6-SOIC Variation	Over Current Over Temperature	100 µA	6 V	Surface Mount
Nisshinbo Micro Devices Inc. R1172N111D-TR-FE		85 °C	-40 C	1.1 V	1 A	70 db	1	Positive	SOT-23-5	Enable		SC-74A SOT-753	Over Current Over Temperature	100 µA	6 V	Surface Mount			0.56 V
Nisshinbo Micro Devices Inc. R1172H361D-T1-FE	0.18 V	85 °C	-40 C	3.6 V	1 A	70 db	1	Positive	SOT-89-5	Enable		SOT-89-5/6	Over Current Over Temperature	100 µA	6 V	Surface Mount
Nisshinbo Micro Devices Inc. R1172S331A-E2-FE	0.18 V	85 °C	-40 C	3.3 V	1 A	70 db	1	Positive	6-HSOP-J	Enable	0.154 in 3.9 mm	4 Leads + 2 Fins 6-SOIC Variation	Over Current Over Temperature	100 µA	6 V	Surface Mount
Nisshinbo Micro Devices Inc. R1172S151B-E2-FE	0.32 V	85 °C	-40 C	1.5 V	1 A	70 db	1	Positive	6-HSOP-J	Enable	0.154 in 3.9 mm	4 Leads + 2 Fins 6-SOIC Variation	Over Current Over Temperature	100 µA	6 V	Surface Mount
Nisshinbo Micro Devices Inc. R1172D261B-TR-FE	0.18 V	85 °C	-40 C		1 A	70 db	1	Positive	6-HSON	Enable		6-SMD Flat Leads Exposed Pad	Over Current Over Temperature	100 µA	6 V	Surface Mount	2.8	2.9		2.6 V
Nisshinbo Micro Devices Inc. R1172S121D-E2-FE		85 °C	-40 C	1.2 V	1 A	70 db	1	Positive	6-HSOP-J	Enable	0.154 in 3.9 mm	4 Leads + 2 Fins 6-SOIC Variation	Over Current Over Temperature	100 µA	6 V	Surface Mount			0.56 V
