AHM Series

Manufacturer: XP Power

Catalog

DESKTOP AC ADAPTERS PSU, 100W, EXTERNAL, MEDICAL + IND

Part	Weight	Weight	Current - Output (Max) [Max]	Operating Temperature [Max]	Input Type	Power (Watts)	Region Utilized	Standard Number	Cord Length	Cord Length	Efficiency	No Load Power Consumption	Applications	Voltage - Input [Min]	Voltage - Input [Max]	Output Connector	Form	Voltage - Output	Input Connector	Approval Agency	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Weight [custom]	Weight [custom]	Output Connector
XP Power AHM100PS24	1.1 lbs	499 g	4.16 A	60 °C	Cord (Sold Separately)	100 W	International	60601-1; 62368-1	0.9 m	35.4 in	Level V	500 mW	ITE (Commercial) Medical	80 VAC	264 VAC	Power DIN 4 Pin	Desktop (Class I)	24 V	IEC 320-C14	CB TUV UL	6.29 in	2.52 in	64 mm	37 mm	160 mm	1.45 in
XP Power AHM100PS24C2-8			4.16 A	60 °C	Cord (Sold Separately)	100 W	International	60601-1; 62368-1	0.9 m	35.4 in	Level V	500 mW	ITE (Commercial) Medical	80 VAC	264 VAC	Power DIN 4 Pin	Desktop (Class II)	24 V	IEC 320-C8	CB TUV UL	6.29 in	2.52 in	64 mm	37 mm	160 mm	1.45 in
XP Power AHM100PS12			8.33 A	60 °C	Cord (Sold Separately)	100 W	International	60601-1; 62368-1	0.9 m	35.4 in	Level V	500 mW	ITE (Commercial) Medical	80 VAC	264 VAC	Power DIN 4 Pin	Desktop (Class I)	12 V	IEC 320-C14	CB TUV UL	6.29 in	2.52 in	64 mm	37 mm	160 mm	1.45 in
XP Power AHM250PS15T			14.66 A	60 °C	Cord (Sold Separately)	220 W	International	60601-1; 62368-1	0.9 m	35.4 in	Level V	500 mW	ITE (Commercial) Medical	80 VAC	264 VAC	Rectangular	Desktop (Class I)	15 V	IEC 320-C14	CB TUV UL	8.8 in	3.48 "	88.5 mm	37 mm	223 mm	1.45 in	2.3 lbs	1 kg	6 Position
