833-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 34POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Card Type | Read Out | Contact Finish | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Number of Rows [custom] | Contact Type | Contact Material | Number of Positions/Bay/Row [custom] | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Finish Thickness | Contact Finish Thickness | Number of Positions [custom] | Mounting Type | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows | Number of Rows | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Dual | Gold | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | 2 | Cantilever | Copper Alloy | 17 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Single | Gold | Wire Wrap | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | 1 | 1 | 34 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Dual | Gold | Solder | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Female | 2 | Cantilever | Copper Alloy | 17 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Right Angle Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Dual | Gold | Solder | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Female | 2 | Cantilever | Copper Alloy | 17 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Board Edge Straddle Mount | 3.96 mm | 0.156 in | 125 °C | -40 C | Card Extender | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Single | Gold | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | 1 | 1 | 34 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Dual | Gold | Solder | 3.96 mm | 0.156 " | Female | 2 | Cantilever | Copper Alloy | 17 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Board Edge Straddle Mount | 3.96 mm | 0.156 in | 125 °C | -40 C | Card Extender | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Single | Gold | Solder | 3.96 mm | 0.156 " | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Right Angle Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | 1 | 1 | 34 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Single | Gold | Solder | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Right Angle Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | 1 | 1 | 34 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Dual | Gold | Solder | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Female | 2 | Cantilever | Copper Alloy | 17 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Dual | Gold | Wire Wrap | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Female | 2 | Cantilever | Copper Alloy | 17 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 0.25 Ám | 10 Áin | 34 | Through Hole | 3.96 mm | 0.156 in | 125 °C | -40 C |
