395-049 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 49POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Positions | Contact Type | Read Out | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Color | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Features | Number of Positions/Bay/Row | Mounting Type | Gender | Card Type | Termination | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | Card Guides | 49 | Through Hole | Female | Non Specified - Single Edge | Solder | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 49 | Through Hole | Female | Non Specified - Single Edge | Solder | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | Card Guides | 49 | Through Hole | Female | Non Specified - Single Edge | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | Card Guides | 49 | Right Angle Through Hole | Female | Non Specified - Single Edge | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | Card Guides | 49 | Through Hole | Female | Non Specified - Single Edge | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 49 | Through Hole | Female | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 49 | Right Angle Through Hole | Female | Non Specified - Single Edge | Solder | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 49 | Through Hole | Female | Non Specified - Single Edge | Solder | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 49 | Through Hole | Female | Non Specified - Single Edge | Wire Wrap | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 49 | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Black | 0.1 " | 2.54 mm | -40 C | 105 ░C | Copper Alloy | 49 | Through Hole | Female | Non Specified - Single Edge | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
